container office building & cabins designs

 Royal Prefab is one of the best container Office Manufacturers in Delhi NCR, manufacturing MS Portable Container offices, Container cabins, Construction Site Office containers & Portable Office. These items are made by using Preeminent Quality Material, bought from the most valid and Affirmed sellers. The offered items are Created by a group of experienced experts Utilizing mechanically the most recent hardware at the Creation Premise.

Bottom: ISMC of 100 mm x 50 mm.   Top frame: 50mm x 50mm Square Pipe Stiffener Bottom: ISMC 75 x 40 base frame with 60 x 40 x 4mm pipe  Stiffener Top: 40x 20mm Tubes. Side post : 65mm x 65mm Square Pipe.

 For 20Ft 50x50mm Square tube

Paneling Outside : Specially MS Grooved Sheet - 1.2mm thick sheet.   Internal wall paneling:8mm Waterproof & termite proof Board. Roof Outside : Specially MS Sheet - 1.2 mm thick Properly Sloped and water tight.

Ceiling : 8mm Waterproof & termite proof Board.  Flooring system: 18mm waterproof ply/ cement fiber board with Vinyl Carpet. Wall with inbuilt Glass: 18'(L)x 2.5'(H),(3 Equal Segment of 6'(L)x2.5'(H)x0.3''(T)-Properly sealed against water ingress), Toughned Glass,Black colour, Visibility from inside to be provided at center of one wall marked as per  layout.   Vertical Blinds: 3 Nos-On each Inbuilt Glass Segment

Doors: Frame work of 30mm x 30mm Square Pipe, external wall made of M.S.Sheet of 1.2 mm thick & inner wall decorated with 10mm Waterproof & termite proof board & suitable locking system.Insulation : Glass wool density of 48kg/m3, Glass wool Insulation of 50mm thick on all 4 walls and on the ceiling.

Outside Paint: Painting with 1coat of Epoxy primer with Two Coat of Epoxy Paint(Olive Drab).

Bottom support legs : Legs from M.S. Sq. Pipes  Corners: Steel ISO Corners (8 Nos.)Corner Support: 200mm height Structural support on each corner below shelter  base.

Bottom: ISMC of 100 mm x 50 mm.  Top frame: 50mm x 50mm Square Pipe                                                                        Stiffener Bottom: ISMC 75 x 40 base frame with 60 x 40 x 4mm pipe  Stiffener Top: 40x 20mm Tubes. S ide post : 65mm x 65mm Square Pipe. For 40Ft 65x65mm Square tube

Paneling Outside : Specially MS Grooved Sheet - 1.2mm thick sheet. Internal wall paneling:8mm Waterproof & termite proof Board.                                     Roof Outside : Specially MS Sheet - 1.2 mm thick Properly Sloped and water tight.

Ceiling : 8mm Waterproof & termite proof Board.  Flooring system: 18mm waterproof ply/ cement fiber board with Vinyl Carpet.                                                                                                               Wall with inbuilt Window: 3ftx3ft- 6Nos -Properly sealed against water ingress),  Glass,Black colour, Visibility from inside to be provided at center of one wall marked as per layout.

 Vertical Blinds: 3 Nos-On each Inbuilt Glass Segment

Doors: Frame work of 30mm x 30mm Square Pipe, external wall made of M.S.Sheet of 1.2 mm thick & inner wall decorated with 10mm Waterproof & termite proof board & suitable locking system.

Insulation : Glass wool density of 48kg/m3, Glass wool Insulation of 50mm thick on all 4 walls and on the ceiling.

Outside Paint: Painting with 1coat of Epoxy primer with Two Coat of Epoxy Paint(Olive Drab).

Bottom support legs : Legs from M.S. Sq. Pipes  Corners: Steel ISO Corners (12 Nos.)

Corner Support: 200mm height Structural support on each corner below shelter base.
